What is the formula for time period in seismic analysis?

As per the formula provided in IS code (IS 1893(part1):2002), the time period value obtained, . = 0.7475 sec Where h=height of the building in the model provided h=21.45m The above calculation is done manually just considering the overall height of the building.

Then, how do you find the time period of a structure?

Tn =2π√(m/k) where,

1. Tn is a natural period of building.
2. m is mass.
3. k is stiffness.

Subsequently, question is, what is earthquake time period? The time taken by the wave to complete one cycle of motion is called period of the earthquake wave. In general, earthquake shaking of the ground has waves whose periods vary in the range 0.03-33sec. Even within this range, some earthquake waves are stronger than the others.

In this way, what is time period of a building?

Natural Period Tn of a building is the time taken by it to undergo one complete cycle of oscillation. It is an inherent property of a building controlled by its mass m and stiffness k. (with smaller stiffness k) have larger natural period than light and stiff buildings.

What is meant by the term time period?

Time Period (T): Time taken to complete one complete cycle is called Time period. For example if a cyclist is moving on circular track with uniform speed, then its time period will be equal to the time required to cover one complete rotation.

Related Question Answers

Is Etabs a code?

I will do seismic analysis and design by ETABS with IS CODE because I am doing it in INDIA and with BS CODE because I am from Africa we follow BS CODE.

Seismic Analysis of Structures By Etabs in B.S Code & I.S Code.

Name	Type
RS Y	Response Spectrum
TH X	Nonlinear Modal History (FNA)
TH Y	Nonlinear Modal History (FNA)
push X	Nonlinear Static

What are the different types of seismic analysis?

Three basic methods are available for analyzing the responses of a structure subjected to seismic ground wave: Static analysis. Response spectra analysis. Time history analysis.

What is Response Reduction Factor?

Response reduction factor is the factor by which the actual base shear force should be reduced, to obtain the design lateral force during design basic earthquake (DBE) shaking. The response reduction factor (R) is basically depends on Over strength (Rs), Ductility (Rµ), Redundancy (RR).

How do you calculate the base shear of a building?

The base shear formula is: V = 0.2 (W) V represents the shear force that will be generated at the base of a building. 0.2 represents earthquake force. W represents the weight of the building.

What is base shear?

Base shear is an estimate of the maximum expected lateral force on the base of the structure due to seismic activity. It is calculated using the seismic zone, soil material, and building code lateral force equations (Figure 10.3). Proximity to potential sources of seismic activity (such as geological faults)

What is natural time period and frequency?

Period refers to the time it takes something to happen. Frequency is a rate quantity. Period is a time quantity. Frequency is the cycles/second. Period is the seconds/cycle.

What is natural period?

: the period of one complete oscillation of a body or system.

What is a short period building?

To define the structure as long or short period, you need the design spectra. The dividing point is the end of the constant acceleration range (the flat part of the spectra). If the first period of the building is before this point, this is a short-period building.

What is fundamental period?

The fundamental period of a function is the period of the function which are of the form, f(x+k)=f(x) f(x+k)=f(x), then k is called the period of the function and the function f is called a periodic function.

What does the R factor account for?

R factor is the ratio of strength required to maintain structural elasticity in force-based seismic design procedures. This factor is important in estimating the seismic force of a structural building.

What is fundamental period of structure?

For seismic-resistant structures each structure has a unique natural or fundamental period of vibration, which is the time required for one cycle of free vibration. Parameters: The factors determining the fundamental period include structure stiffness and height.

What is a short period earthquake?

Short buildings, say, less than 7 stories, have short natural periods, say, 0.2-0.6 sec. Tall buildings have long natural periods, say 0.7 sec or longer. A earthquake strong motion record is made up of varying amounts of energy at different periods.

What are Indian seismic codes?

Today, the Bureau of Indian Standards (BIS) has the following seismic codes: IS 1893 (Part I), 2002, Indian Standard Criteria for Earthquake Resistant Design of Structures (5th Revision) IS 4326, 1993, Indian Standard Code of Practice for Earthquake Resistant Design and Construction of Buildings (2nd Revision) IS 13827

How do we measure magnitude of earthquake?

The Richter magnitude of an earthquake is determined from the logarithm of the amplitude of waves recorded by seismographs. Adjustments are included for the variation in the distance between the various seismographs and the epicenter of the earthquakes.

Was there an earthquake in 1893?

It is to serve this purpose that IS 1893 : 1962 'Recommendations for earthquake resistant design of structures' was published and revised first time in 1966. In the clauses for design of multi-storeyed buildings, the coefficient of flexibility was given in the form of a curve with respect to period of buildings.

How does the period of an earthquake relate to a building's natural period?

All buildings have a natural period, or resonance, which is the number of seconds it takes for the building to naturally vibrate back and forth. If the period of ground motion matches the natural resonance of a building, it will undergo the largest oscillations possible and suffer the greatest damage.

What is period structure?

The longest-period mode is called the fundamental mode, and it's period of vibration is called the structure's natural period of vibration. The period of the fundamental mode is also called the fundamental period. The longer period modes are called lower modes, while shorter period modes are called higher modes.

What is importance factor?

The Importance Factor is a multiplier that increases or decreases the base design loads. Therefore, an elevated Importance Factor creates proportionally higher design loads (i.e., a wind Importance Factor of 1.15 is a 15% increase in design wind loads).

What type of force is an earthquake?

Earthquake forces are called lateral forces because their predominant effect is to apply horizontal loads to a building. Figure 1. Inertial forces are a reaction to acceleration.
